General:
StatusActive
CategoryCrimp Terminals
Series19420
ApplicationPower
CommentsUL EI52602
OverviewMX150L? Industrial Sealed Connector System
Product Literature Order No987650-2181
Product NameMX150L?
UPC756054795576
Physical:
Flammability94V-0
GenderFemale
Material - MetalHigh Performance Alloy (HPA)
Material - Plating MatingTin
Material - Plating TerminationTin
Net Weight0.395/g
Packaging TypeReel
Plating min - Mating1.905μm
Plating min - Termination1.905μm
Termination Interface: StyleCrimp or Compression
Wire Insulation Diameter2.87 -3.53mm
Wire Size AWG14, 16
Wire Size mm2N/A
Agency Certification:
Please find UL Certificates by searching the UL Database using the Molex Series Number. Click here to visit the UL Database
CSALR18689
ULE152602
