General:
StatusActive
CategoryCrimp Housings
Series51047
ApplicationSignal, Wire-to-Wire
Current Derating Order No987651-3691
OverviewPicoBlade? Connector System
Product NamePicoBlade?
UPC800753756922
Physical:
Circuits (maximum)4
Color - ResinNatural
GenderMale
Glow-Wire CompliantNo
Lock to Mating PartYes
Material - ResinPolyester
Net Weight81.900/mg
Number of Rows1
Packaging TypeBag
Panel MountNo
Pitch - Mating Interface1.25mm
StackableNo
Temperature Range - Operating-40°C to +85°C
Agency Certification:
Please find UL Certificates by searching the UL Database using the Molex Series Number. Click here to visit the UL Database
ULE29179
6710 BL013
6710 BL005
6710 BL001
6710 BK005
