General:
StatusActive
CategoryCrimp Housings
Series5195
ApplicationSignal, Wire-to-Board
OverviewSPOX? Wire-to-Board Connectors
Product NameSPOX?
UPC800753534452
Physical:
Circuits (maximum)6
Color - ResinNatural
Flammability94V-2
GenderFemale
Glow-Wire CompliantNo
Material - ResinNylon
Net Weight1727.900/mg
Number of Rows1
Packaging TypeBag
Panel MountNo
Pitch - Mating Interface3.96mm
Pitch - Termination Interface3.96mm
StackableNo
Temperature Range - Operating-40°C to +105°C
Agency Certification:
Please find UL Certificates by searching the UL Database using the Molex Series Number. Click here to visit the UL Database
CSALR19980
ULE29179
Material Info:
Engineering Number5195-06
6710 BL013
6710 BL005
6710 BL001
6710 BK005
