General:
StatusActive
CategoryCrimp Housings
Series41695
ApplicationPower, Wire-to-Board
OverviewKK? Interconnect System - Molex
Product NameKK? 396
UPC800754227711
Physical:
BreakawayNo
Circuits (maximum)5
Color - ResinNatural
Flammability94V-0
GenderFemale
Glow-Wire CompliantNo
Keying to Mating PartNone
Lock to Mating PartYes
Material - ResinPolyester
Net Weight1.746/g
Number of Rows1
Packaging TypeBag
Panel MountNo
Pitch - Mating Interface3.96mm
Temperature Range - OperatingSee Product Specification
Agency Certification:
Please find UL Certificates by searching the UL Database using the Molex Series Number. Click here to visit the UL Database
CSALR19980
ULE29179
Solder Process Data:
Solderability Shelf Life Statement
Lead-freeProcess CapabilityN/A
Material Info:
Engineering Number41695-N-B05
6710 BL013
6710 BL005
6710 BL001
6710 BK005
